TD-401

Desktop Barcode Printer

· High-Performance MCU with Large-Capacity Control: New domestic MCU chip and external flash memory eliminate printing lag and incomplete content.

· Memory Function with Auto Reprint: Automatically reprints at breakpoints to ensure no labels are missed.

· High-Speed Printing: Prints at 152mm/s, delivering 60 labels per minute, doubling efficiency.

· Precise Positioning: Multi-sensor technology ensures accurate positioning, zero errors, and uninterrupted printing.

· Dual-Mode Connectivity: Supports Bluetooth and Wi-Fi for seamless switching and flexible connections.

Overview
Product Specification
Download

Aiprint

Desktop

System Docking

Barcode printing

Application

Warehousing Logistics

Medical Labeling

Folder Labeling

Storage Labeling

Features

Model	Desktop Barcode Printer TD-401
Print head dpi	203DPI
Printing method	Thermal
Interface	USB or USB+Bluetooth+WiFi
Emulation	TSPL、ZPL、CPCL、DPL、EPL
Sensor	Gap sensor/open cover sensor/Black label sensor
Print speed	152mm/s（max）
Printing width	108mm（max）
Printing length	1778mm（max）
SDRAM	SDRAM 8MB
FLASH	FLASH 8MB（expandable）
Driver support system	Windows：Windows 7/10/11（32 bit/64 bit）
	MacOS：10.9/10.10/10.11/10.12/10.13/10.14/10.15/11.6/12.1/12.2/12.3/12.4/14.4/14.6
	Linux Ubuntu： 18.04/20.04/22.04/24.04
	Astra Linux Special Edition V1.6
APP support system	Android 6.0 and above
APP support system	iOS 11 and above
Bar code format	Code128、EAN128、ITF、Code39、Code93、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CodeBar、Postnet、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、MSI、MSIC、PLESSEY、CPOST、ITF14、EAN14、Code11
Two-dimensional code format	QR code、PDF417、Micro PDF 417、DataMatrix、AZTEC
Character enlargement/rotation	1-10x magnification /0°, 90°, 180°, 270° rotation/mirror printing
Character	GB18030、BIG5、ASCII
Extended character	PC437、Katakana、PC850、PC860、PC863、PC865、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866、PC852、PC858、IranII、Latvian、Arabic、PT151、PC747、WPC1257 and other languages, 61 kinds in total
Character size	9x17dot, 12x24dot, 24x24dot
Paper type	Gap Label, Continuous Label, Black Mark Label, Folded Label
Roll width (including backing paper)	30~114mm
Roll thickness (including backing paper)	0.12~0.26mm
Paper axis size	25.4mm
Roll outside diameter	120mm（OD）
FEED	Front exit
Power	Input power supply: AC100 〜240V Output power: DC 24V~2.5A
Working environment	Operating temperature: 5~40°C Operating humidity: 25~85%
Storage environment	Storage temperature: -10~60℃ Storage humidity: 10~90%
Print head life	150km(Print rate 18.5%)
Dimension	210 * 168.5 * 152.5 mm
Weight	1.2KG
Accessories (standard)	1. Power adapter 2. Power cord 3. USB cable 4. Quick installation Guide 5, paper reel, paper roll baffle 2 6,Printing consumables 1
Certification	CCC, CE, ROHS, REACH, TELEC (Japan), EAC (Russia), FAC (Russia), SRRC，BIS（India)
